Molded PTFE Rods
Molded PTFE Rods are used for processing various gaskets, seals and lubrication materials work in corrosive media and an electrically insulating parts used at various frequencies such as PTFE resin filled not added by molding, paste extrusion or ram extrusion molding process bars. Model:KXT R980
Send Inquiry
Product Description
Molded PTFE Rods – High‑Purity, Chemically Inert Rod Stock for Precision Components
Kaxite Sealing is a leading China-based manufacturer and supplier of molded PTFE rods – high‑quality rod stock produced from 100% virgin PTFE resin through advanced compression molding or ram extrusion processes. Available in a wide range of diameters and lengths, our PTFE rods offer exceptional chemical resistance, continuous service from -200°C to +260°C, outstanding dielectric properties, and a low coefficient of friction. They are the material of choice for machining custom gaskets, seals, bearings, electrical insulators, and medical components. Kaxite also supplies filled PTFE rods (glass, carbon, graphite, bronze, etc.) to meet specific mechanical or electrical requirements.
As a trusted factory direct supplier in China, Kaxite offers custom diameters and lengths, filled compounds, and competitive wholesale pricing. Request your price list and free sample →
Why Molded PTFE Rods?
Chemically Inert
Resists almost all chemicals – ideal for corrosive environments.
High Thermal Resistance
Continuous use from -200°C to +260°C (short‑term to 300°C).
Excellent Electrical Insulation
High dielectric strength – perfect for electronics and aerospace.
Self‑Lubricating
Low friction coefficient – ideal for bearings and seals.
Technical Specifications – Molded PTFE Rods
* Custom diameters, lengths, and filler compounds available. Contact our technical team.
Complete dimensional and physical data sheet
Key Advantages
- ✅ Superior chemical resistance – unaffected by acids, alkalis, solvents, and corrosive media
- ✅ Excellent thermal stability – from cryogenic to high temperature, maintains mechanical properties
- ✅ Outstanding electrical insulation – high dielectric strength, low dissipation factor
- ✅ Self‑lubricating – low friction and wear, ideal for dry‑running bearings and seals
- ✅ Easy to machine – can be turned, milled, drilled, and tapped to precision components
Typical Applications
Manufacturing Methods & Filled PTFE Rod Options
Molded PTFE Rods
- ✅ Produced by compression molding
- ✅ Larger diameters (up to 400 mm)
- ✅ Excellent dimensional stability
- ✅ Ideal for short‑run, custom sizes
Extruded PTFE Rods
- ✅ Continuous ram or paste extrusion
- ✅ Smaller diameters (5–100 mm)
- ✅ Longer lengths, consistent quality
- ✅ Cost‑efficient for high‑volume orders
* Both molded and extruded rods are available at Kaxite – consult us to select the best option for your application.
Frequently Asked Questions – Molded PTFE Rods
What is the maximum temperature for PTFE rods?
PTFE rods can operate continuously up to 260°C (500°F), with short‑term peaks up to 300°C. At the low end, they remain flexible down to -200°C.
What are the advantages of filled PTFE rods over virgin PTFE?
Filled grades (glass, carbon, graphite, bronze) offer improved wear resistance, thermal conductivity, higher compressive strength, and lower creep compared to virgin PTFE, making them suitable for dynamic applications like bearings and seals.
Can you supply custom diameters and lengths?
Absolutely. We offer custom diameters from 5 mm to 400 mm and custom lengths up to 3000 mm. Please provide your specifications for a tailored quotation.
Are PTFE rods FDA‑compliant?
Yes, our virgin PTFE rods comply with FDA regulation 21 CFR 177.1550 and are suitable for food, beverage, and pharmaceutical contact applications.
What is the difference between molded and extruded PTFE rods?
Molded rods are compression‑molded in a press, allowing larger diameters and custom shapes. Extruded rods are produced by continuous extrusion, offering longer lengths and consistent quality for smaller diameters.
Why Source from Kaxite Sealing – Your Trusted PTFE Rod Supplier in China
- ✔ 20+ years of PTFE processing expertise
- ✔ ISO 9001 certified manufacturing
- ✔ Exported to 40+ countries worldwide
- ✔ In‑house molding & extrusion capabilities
- ✔ Custom diameters & lengths – any size
- ✔ Filled compounds – glass, carbon, graphite, bronze
- ✔ Flexible logistics – sea, air, express from Ningbo/Shanghai
- ✔ 24/7 technical support – prompt response to inquiries
Packaging & Worldwide Delivery
* Custom packaging and labelling available. View packaging & shipping details →
Ready to Order? Contact Kaxite – China's Reliable Molded PTFE Rod Manufacturer
As a premier China supplier of PTFE rods, Kaxite provides high‑quality products at factory‑direct prices. Whether you need a sample, a price list, or a bulk order, our experienced team is ready to support you with technical advice and prompt service.
